SCORPIO 38’ - 45’ - DOCUMENTATION - PINOUTS
Version 1.02 May 27, 2022
SERVICEVISION BIS SL
Ríos Rosas, 20 · 08940 CORNELLA DE LLOBREGAT (Barcelona) Spain · Tel. 34 93 223 86 30 · Fax 34 93 223 86 31 95
comercial@servicevision.es · www.servicevision.es
Encoders OUT (DB connector 25 female DB-25S-A191-A1977)
1 NC
2 NC
3 NC
4 NC
5 NC
6 NC
7 NC
8 NC
9 NC
10 A+ ARM (Green)
11 A- ARM (Blue)
12 B+ ARM (White)
13 B- ARM (Brown)
14 A+ PAN CRANE (Red)
15 A- PAN CRANE (Black)
16 B+ PAN CRANE (Yellow)
17 B- PAN CRANE (Orange)
18 A+ TILT CRANE (Green)
19 A- TILT CRANE (Blue)
20 B+ TILT CRANE (White)
21 B- TILT CRANE (Brown)
22 A+ TRACK CRANE (Green)
23 A- TRACK CRANE (Blue)
24 B+ TRACK CRANE (White)
25 B- TRACK CRANE (Brown)
26 NC
27 NC
