SCORPIO 38’ - 45’ - DOCUMENTATION - PINOUTS
Version 1.02 May 27, 2022
94
9 DOCUMENTATION
9.1 PINOUTS
Connectors in the Electronic Box:
AC Power out for P.U. (BURNDY 4 pins female panel
UT100-104 ST)
1 220/110 V PHASE (Blue)
2 NC
3 220/110V NEUTRAL (Yellow)
4 GROUND (Yellow-Green)
12V/3A DC OUT (NEUTRIK 4 pins female
panel NC4 FP1)
1 GROUND (Black)
2 NC
3 NC
4 VCC +12V (Red)
Cable levelling Head (BRUNDY 8 pins female
panel UTGO 128S)
1 VCC +28V (Red)
2 GROUND (Black)
3 TILT ENC B1+ OUT (Green)
4 TILT ENC B1 - OUT (Blue)
5 485 - (Grey)
6 485 + (Blue)
7 TILT ENC A1- OUT (White)
8 TILT ENC A1+ - OUT (Brown)
Hand command digital (NEUTRIK 7pins female
panel NC7FP1)
1 VCC +5V (Red)
2 GND (Black)
3 485 N (White)
4 485 P (Green)
5
6
7
Encoder travelling red (LEMO 10 pin female panel EGG -2B.310.CYM)
1 VCC (Red)
2 GROUND (Black)
3 ENC A+ (Green)
4 ENC A- (Blue)
5 ENC B+ (White)
6 ENC B- (Brown)
7 NC
8 NC
9 NC
10 NC
Connector control interface (NEUTRICK 6 pins female
panel N66FD_LX)
1
2
3
4
5 485 (Grey)
6 485 (Pink)
Display Command (NEUTRICK 8 pins female
panel ORP8F)
1 VCC +5V (Red)
2 GND (Black)
3 BUSY (Purple)
4 DOUT (Grey)
5 DIN (Blue)
6 VCC +12V (Orange)
7 GND (Brown)
8 DAMPING (Yellow)
Encoder pan grey (LEMO 10 pin female panel EGG -2B.310.CYM)
1 VCC (Red)
2 GROUND (Black)
3 ENC A+ (Green)
4 ENC A- (Blue)
5 ENC B+ (White)
6 ENC B- (Brown)
7 NC
8 NC
9 NC
10 NC
Encoder tilt blue (LEMO 10 pin female panel EGG -2B.310.CYM)
1 VCC (Red)
2 GROUND (Black)
3 ENC A+ (Green)
4 ENC A- (Blue)
5 ENC B+ (White)
6 ENC B- (Brown)
7 NC
8 NC
9 NC
10 NC
