CDHD Product Description
User Manual 7
2.2.2 Mechanical and Electrical Specifications - 200V
Single and Three-
Phase 200V
Specification
CDHD-
1D5
CDHD-
003
CDHD-
006
CDHD-
013
Ratings
Input Power Main Circuit
(L1, L2, L3)
Voltage (VAC Line-Line) Nominal
±10%
110 to
230
110 to
230
110 to 230 110 to 230
115 VAC 1 Phase 1 Phase
1 Phase or
3 Phase
1 Phase or
3 Phase
230 VAC 1 Phase 1 Phase 1 Phase 1 Phase
Line Frequency (Hz) 47-63 47-63 47-63 47-63
KVA at 115 VAC
KVA at 230 VAC
Continuous Current (A)
Peak Current (A) for 2 sec
Withstand Voltage (Primary to
Ground)
Line Fuses (FRN-R, LPN, or
equivalent)
Logic Input Power
(L1C, L2C)
115 or 230 VAC 1 Phase 1 Phase 1 Phase 1 Phase
Motor Output
(U,V,W)
Continuous Output Current (A rms) 1.5 3 6 13
Continuous Output Current (A
peak)
2.12 4.24 8.485 18.38
Peak Output Current (A rms) for
2 sec
4.5 9 18 26
Peak Output Current (A peak) for
2 sec
6.3 12.72 25.455 36.76
PWM Frequency (kHz) 16 16 16 8
Soft Start Max. Surge Soft Start Current (A) 6
Max. Charge Time (ms) 250
Hardware
Unit Weight (kg) 0.9
Connection Hardware PE Ground Screw Size/ Torque
M4/
1.35 Nm
Wire Size
Control Circuit (AWG) up to 3
meter
24-28
Main Circuit Motor Lines (AWG) 14-16
Main Circuit AC Inputs (AWG) 14-16
PE Ground Screw 14
Clearance Distance Side-to-Side (mm) 10-15
Top/Bottom (mm) 50
Voltage Trip
Under-Voltage Trip (nominal)
(VDC)
100
Over-Voltage Trip (VDC) 420
