Servotronix CDHD - Mechanical and Electrical Specifications - 400 V

Product Description CDHD
8 Servotronix
Single and Three-
Phase 200V
Specification
CDHD-
1D5
CDHD-
003
CDHD-
006
CDHD-
013
Power Temperature
Power Over-Temperature Warning
(°C)
100
Power Over-Temperature Fault (°C) 110
Trigger Temperature for High-
speed Fan (°C)
NA NA 60
Regen External
Regenerative resistor
(B1+, B2)
External Shunt
Regulator
Peak current (A) NA NA 30
Minimum resistance (Ω) NA NA 13.1
Watts NA NA
system
dependent
Application Information Capacitance (F) NA NA 1120
Bus Voltage (nominal) (VDC) NA NA 320
VHYS (Regen Circuit Turn-off) VDC) NA NA
VMAX (Regen Circuit Turn-on)
(VDC)
NA NA
2.2.3 Mechanical and Electrical Specifications - 400V
Three-Phase 400V Specification CDHD-003 CDHD-006
Ratings
Input Power Main Circuit Voltage (VAC Line-Line) Nominal ±10% 530-600 530-600
(L1, L2, L3) 380 VAC 3 Phase 3 Phase
430 VAC 3 Phase 3 Phase
Line Frequency (Hz) 47-63 47-63
KVA at 380 VAC
KVA at 430 VAC
Continuous Current (A)
Peak Current (A) for 2 sec
Withstand Voltage (Primary to Ground)
Line Fuses (FRN-R, LPN, or equivalent)
Logic Input Power
(L1C, L2C)
VDC 24 VDC ±10% 24 VDC ±10%
Motor Output
(U,V,W)
Continuous Output Current (A rms) 3 6
Continuous Output Current (A peak) 4.24 8.485
Peak Output Current (A rms) for 2 sec 9 18
Peak Output Current (A peak) for 2 sec 12.72 25.455
PWM Frequency (kHz) 16 16
Soft Start Max. Surge Soft Start Current (A)
Max. Charge Time (ms)
