Super II • User Functions 21
PART ID
APW COUNT MORE EXIT
Enter ID, Tare, APW, or Count.
1 2 3 4
abc reset
menu remote
tare
F1 F2 F3 F4 F5
F8
F9
F10 F12
F11
Operating Your Scale Using a QWERTY Keyboard
The back of the removable controller has a port for a standard PS/2® style computer keyboard. To remove
the controller from the base, please refer to Section 1, Setting Up Your Scale. Once a QWERTY keyboard is
attached to the controller, all scale operations can be performed from the keyboard or in combination with
the scale’s controller.
Using the Function Keys F1 - F5
The function keys F1 - F5 correspond to the soft key functions shown on the bottom of the display. That is,
F1 corresponds to the soft key furthest on the left. F2 corresponds to the second soft key and so on. When
the scale is in the default mode, the F1 key can be used to ZERO the scale, the F2 key will recall the SAMPLE
size, the F3 key will initiate a COUNT, the F4 key will PRINT, the F5 key will CLEAR and return to weight.
Example functions in the default menu:
F1 = ZERO
F2 = SAMPLE
F3 = COUNT
F4 = PRINT
F5 = CLEAR
Using the Function Keys F8 - F12
The F8 - F12 function keys have been reserved for the following hard key functions. F8 is equivalent to the
tare key. F9 will bring up the
menu. F10 will switch to a remote base (or bring up the base selection
menu if multiple bases are attached). F11 will bring up the ID entry soft keys (abc key) and F12 will cause
the scale to do a complete
reset of all volatile scale registers.
Hard key F8 = TARE
function: F9 = MENU
F10 = REMOTE
F11 = ABC
F12 = RESET
Entering Numeric Information
The number keys 1 - 9 function the same way as they do on the scale’s numeric keypad. Once a number is
pressed, the soft keys change to the following:
Numeric
soft key
labels:
PS/2® is a registered trademark of IBM.
