SEW-Eurodrive Movidrive MDX61B User Manual

5
Startup
Starting the motor
Operating Instructions – MOVIDRIVE
®
MDX60B/61B
160
5.5 Starting the motor
5.5.1 Analog setpoint input
The following table shows the signals that must be present on terminals X11:2 (AI1)
and X13:1–X13:6 (DIØØ–DIØ5) when the "UNIPOL/FIX.SETPT" setpoint is selec-
ted (P100) to operate the drive with an analog setpoint input.
Function X11:2
(AI11)
Analog in-
put n1
X13:1
(DIØØ)
/Control-
ler inhibit
X13:2
(DIØ1)
CW/Stop
X13:3
(DIØ2)
CCW/
stop
X13:4
(DIØ3)
Enable/
stop
X13:5
(DIØ4)
n11/n21
X13:6
(DIØ5)
n12/n22
Controller inhibit X "0" X X X "0" "0"
Stop X "1" X X "0" "0" "0"
Enable and stop X "1" "0" "0" "1" "0" "0"
Clockwise at 50%
n
max
5 V "1" "1" "0" "1" "0" "0"
Clockwise at n
max
10 V "1" "1" "0" "1" "0" "0"
Counterclockwise at
50% n
max
5 V "1" "0" "1" "1" "0" "0"
Counterclockwise at
n
max
10 V "1" "0" "1" "1" "0" "0"
23534850/EN – 11/2017
