5
Startup
Complete parameter list
Operating Instructions – MOVIDRIVE
®
MDX60B/61B
166
5.6 Complete parameter list
5.6.1 General information
• The parameters contained in the standard user menu are marked by a "\" (= dis-
play on the DBG60B keypad).
• The factory setting for the parameter is highlighted in bold.
5.6.2 Display values
Par. Name Factory setting
00. Process values
000 Rotational speed -6100–0–6100min
-1
\001 User display "Text"
002 Frequency 0–599Hz
003 Actual position 0–2
31
-1inc.
004 Output current 0–250% I
N
005 Active current -250–0–250% I
N
\006 Motor utilization 1 0–200%
007 Motor utilization 2 0–200%
008 DC link voltage 0–1000V
009 Output current A
01. Status displays
010 Inverter status
011 Operating state
012 Fault status
013 Current parameter set 1/2
014 Heat sink temperature -40–0–125°C
015 Power-applied hours h
016 Drive running hours h
017 Work kWh
018 KTY capacity utilization 1 0–200%
019 KTY capacity utilization 2 0–200%
02. Analog setpoints
020 Analog input AI1 -10–0–10V
021 Analog input AI2 -10–0–10V
022 External current limiting 0–100%
03. Digital inputs of basic device
030 Digital input DIØØ /CONTROLLER INHIBIT
23534850/EN – 11/2017
