AL-2041 SIMULATION, TROUBLE CODES 10 - 8
26 40 Polygon motor OFF time
setup (Time required for
turning OFF after completion
of printing)
[Function]
When this simulation is executed, the current setting is displayed. Enter the code number corre-
sponding to the desired setting and press [START] key to save the setting.
[Operation]
The operation is similar to simulation 26-02.
42 Transfer ON timing control
setup
[Function]
Enter the code number with [UP/UP] key and press [START] key, and the entered set value is
saved and the machine enters the sub code input standby state.
Use [Density Select] key to select a mode. The set value of the selected mode is displayed in
the 7seg display.
Main
code
Sub
code
Contents Details of function/operation
Code number Setting Display item Remark
00sec0
1 30sec 30 Default
2 60sec 60
3 90sec 90
<Paper lead edge adjustment table>
* The default value, "11," of the transfer ON timing indicates "236msec passed from PS
release."
* When set to "0," it is same as setting to the default, "11."
* The transfer ON timing can be adjusted to 236msec ± 2ms.
<Front/back surface of paper rear edge adjustment table>
* The default "50" of the transfer OFF timing indicates "210msec passed from PPD1OFF."
* The transfer OFF timing can be adjusted to 210msec ± 2ms.
Mode LED Default Setting range
Front surface paper
lead edge
AE mode lamp 11 0 - 21
Front surface paper
rear edge
TEXT mode lamp 50 1 - 99
Back surface paper
lead edge
PHOTO mode lamp 11 0 - 21
Back surface paper
rear edge
AE mode lamp
TEXT mode lamp
50 1 - 99
Code number Setting Code number Setting
0 Default (236 msec) 11 Default (236 msec)
1 –20 msec 12 +2 msec
2 –18 msec 13 +4 msec
3 –16 msec 14 +6 msec
4 –14 msec 15 +8 msec
5 –12 msec 16 +10 msec
6 –10 msec 17 +12 msec
7 –8 msec 18 +14 msec
8 –6 msec 19 +16 msec
9 –4 msec 20 +18 msec
10 –2 msec 21 +20 msec
Code Setting Remark
1 –98 msec
. . . . . .
49 –2 msec
50 0 msec Default
51 +2 msec
. . . . . .
99 +98 msec
