16
Initial auto installation
When the TV powers on for the first time after purchase,
the initial auto installation wizard appears. Follow the
menus and make the necessary settings one after
another.
Confirm the following before turning on the
power
E
Is the antenna cable connected?
E
Is the AC cord plugged in?
1 Press < on the TV.
• The initial auto installation wizard appears.
2 Setting the OSD language.
Press a/b to select the desired language, and then press
ENTER.
3 Selecting the location of the TV.
Press c/d to select where you will use this TV, and then
press ENTER.
HOME:
• Settings are optimised for normal home viewing and
energy efficiency.
• “STANDARD” will be the default value for the “AV mode”
setting.
STORE:
• Settings are designed for maximum impact in retail store
displays.
• “DYNAMIC (Fixed)” will be the default value for the “AV
mode” setting. If the “AV mode” is changed, the TV will
automatically switch back to “DYNAMIC (Fixed)” when
there is no operation using the TV or remote control unit
for 10 minutes.
• The confirmation screen pops up only when selecting
“STORE”. Press c/d to select “Yes” or “No”, and then
press ENTER.
NOTE
• STORE: A demonstration image will be displayed after initial
auto installation is completed. If you have chosen “STORE”
by mistake, go to “Setup” > “View setting” > “Reset” > select
“HOME” again.
4 Press c/d to select “Digital Search” or “Analogue
Search”, and then press ENTER.
5 The TV searches for, sorts and stores all the
receivable TV stations according to their settings
and the connected antenna.
• To abort the initial auto installation in progress, press
C.
NOTE
• If you turn off the power on the TV while performing a channel
search in Step 4, the initial auto installation wizard may not
appear. The auto installation function allows you to execute
the installation again from “Setup” > “View setting” (Page 40).
• The initial auto installation wizard will abort if you leave the TV
unattended for 10 minutes before searching for channels in
Step 5.
Checking signal strength and
channel strength (D-TV only)
If you install a D-TV antenna for the first time or relocate
it, you should adjust the alignment of the antenna to
receive a good reception while checking the antenna
setup screen.
1 Go to “HOME” > “TV Menu” > “Setup” > “View
setting” > “Channel settings” > “Antenna setup-
DIGITAL”.
E
Checking signal strength
2 Press a/b to select “Signal strength”, and then
press ENTER.
Supply voltage
CH No.
Current Max.
Signal strength
Signal strength
Channel strength
Current Max.
Quality
97 97
99 99
E
Checking channel strength
3 Press a/b to select “Channel strength”, and then
press ENTER.
• You can input a specified frequency band using the 0–9
numeric buttons.
Supply voltage
CH No.
Current Max.
Signal strength
MHz
Signal strength
Frequency
Channel strength
Current Max.
Quality
97 97
99 99
4 Position and align the antenna so that the
maximum possible values for “Signal strength”
and “Quality” are obtained.
NOTE
• The values of “Signal strength” and “Quality” indicate when to
check the appropriate alignment of the antenna.
Supplying power to the antenna (D-TV only)
You can supply power to the antenna in order to receive
digitally/terrestrially broadcast stations after connecting
the antenna cable to the antenna terminal on the rear of
the TV.
1 Go to “HOME” > “TV Menu” > “Setup” > “View
setting” > “Channel settings” > “Antenna setup-
DIGITAL” > “Supply voltage”.
2 Press c/d to select “On”, and then press
ENTER.
Quick guide
LC-6070UD1H_EN_book.indb 16LC-6070UD1H_EN_book.indb 16 1/2/2014 8:57:03 AM1/2/2014 8:57:03 AM
