86
Appendix
Removing the stand
For wall mounting with the bracket remove the stand.
Before setting TV on the wall
• Remove the connected cables (DVD, VCR, etc.) from the terminals.
• Before performing work, make sure to turn off the TV.
• Before performing work spread cushioning over the base area to lay the TV on. This will prevent it from being damaged.
NOTE
• To attach the stand, perform the above steps in reverse order.
• As the TV is very heavy, be careful when moving it.
1 Remove the stand cover.
1
Unfasten the screw used to secure the stand cover.
2
Remove the stand cover.
2 Unfasten the four screws used to secure the stand in place.
3 Detach the stand from the TV.
