53
Network function
Specifications (Wireless LAN USB adapter)
Product name 802.11n Dual Band WLAN adapter
Standard IEEE 802.11a/b/g/n
Host interface USB
Frequency band
2412f2484 MHz
5150f5850 MHz
Security Static WEP (64/128 bit, key index 1 only)
WPA-PSK (TKIP)
WPA2-PSK (AES)
Modulation DBPSK@1 Mbps
DQPSK@2 Mbps
CCK@5.5/11 Mbps
BPSK@6/9 Mbps
QPSK@12/18 Mbps
16-QAM@24 Mbps
64-QAM@48/54 Mbps and above, Rx up to 300 Mbps
Transmit
power and
sensitivity
Tx output
power:
(Typical)
2.4 GHz
11b 17 e/f 1.5 dBm
11g 14 e/f 1.5 dBm
11n 13 e/f 1.5 dBm
5 GHz
(5150f5250 MHz,
5250f5350 MHz)
11a 14 e/f 1.5 dBm
11n 13 e/f 1.5 dBm
5 GHz
(5470f5725 MHz,
5725f5850 MHz)
11a 13 e/f 1.5 dBm
11n 13 e/f 1.5 dBm
Rx sensitivity: (Typical)
f84 dBm@11 Mbps
f72 dBm@54 Mbps
f64 dBm@64-QAM, 20 MHz channel spacing
f61 dBm@64-QAM, 40 MHz channel spacing
Current Consumption (5V DC) Tx: 2.2 W (Typical)
Rx: 1.4 W (Typical)
Weight 13 g
Dimensions
20.0 (W) g73.3 (D) g 8.0 (H) mm
Operating temperature
0 °C to e 40 °C
NOTE
• The supplied wireless LAN USB adapter has received the following certifications.
f Wi-Fi CERTIFIED™ (certification programme from the Wi-Fi Alliance®)
f Wi-Fi Protected Setup™ (certification programme from the Wi-Fi Alliance®)
• When there is significant interference in the 2.4 GHz frequency (such as from other wireless LAN devices, Bluetooth® devices, 2.4
GHz cordless telephones, and microwave ovens), it is recommended that you use a wireless LAN access point that supports IEEE
802.11a/n (5 GHz) and set the access point to transmit at 5 GHz. For setup details, see the operation manual of your access point.
• Before transferring to a third party or disposal, be sure to initialise the wireless LAN settings.
• Wireless LAN USB adapter is Peripheral Device for TV and supports WEP64, WEP128, TKIP and AES encryptions.
LC-6070UD1H_EN_book.indb 53LC-6070UD1H_EN_book.indb 53 1/2/2014 8:57:20 AM1/2/2014 8:57:20 AM
