Sharp LCD colour TV - PC Control Command List

69
Command list
CONTROL ITEM COMMAND PARAMETER CONTROL CONTENTS
POWER
SETTING
P O W R 0 _ _ _ POWER OFF (STANDBY)
INPUT
SELECTION
ITGD____
INPUT SWITCHING
(TOGGLE)
ITVD____TV (CHANNEL FIXED)
I D T V _ _ _ _ D-TV (CHANNEL FIXED)
IAVD*___
HDMI 1f4 (1f4),
INPUT 5f7 (5f7),
PC (8)
CHANNEL
DCCH * * _ _
TV DIRECT CHANNEL
(1f99)
C H U P _ _ _ _ CHANNEL UP
C H D W _ _ _ _ CHANNEL DOWN
DTVD* * * _
D-TV DIRECT CHANNEL
(1f999)
DTUP____D-TV CHANNEL UP
DTDW____D-TV CHANNEL DOWN
AV MODE
SELECTION
A V M D 0 _ _ _ TOGGLE
A V M D 1 _ _ _ STANDARD
A V M D 2 _ _ _ MOVIE
A V M D 3 _ _ _ GAME
A V M D 4 _ _ _ USER
A V M D 5 _ _ _ DYNAMIC (Fixed)
A V M D 6 _ _ _ DYNAMIC
AVMD7___PC
A V M D 1 4 _ _ STANDARD (3D)*
1
A V M D 1 6 _ _ GAME (3D)*
1
A V M D 1 7 _ _ MOVIE THX
VOLUME V O L M * * * _
VOLUME (0f100)
POSITION
HPOS * * * _
H-POSITION (AV/PC)
(–nn~nn)
VPOS * * * _
V-POSITION (AV/PC)
(–nn~nn)
CLCK * * * _
CLOCK (0f180)
PHSE * * _ _
PHASE (0f40)
WIDE MODE
W I D E 0 _ _ _ TOGGLE (AV)
W I D E 1 _ _ _ NORMAL (AV)
W I D E 2 _ _ _ ZOOM 14:9 (AV)
W I D E 3 _ _ _ PANORAMA (AV)
W IDE4___
FULL (AV/Multimedia-
Video/Home network-
Video)
W I D E 5 _ _ _ CINEMA 16:9 (AV)
W I D E 6 _ _ _ CINEMA 14:9 (AV)
W I D E 7 _ _ _ NORMAL (PC)
W I D E 8 _ _ _ CINEMA (PC)
W I D E 9 _ _ _ FULL (PC)
W I D E 1 0 _ _ DOT by DOT (AV)
W I D E 1 1 _ _ UNDERSCAN (AV)
W IDE12__
AUTO (Multimedia-
Video/Home network-
Video)
W IDE13__
Original (AV/PC/
Multimedia-Video/Home
network-Video)
CONTROL ITEM COMMAND PARAMETER CONTROL CONTENTS
MUTE
M U T E 0 _ _ _ TOGGLE
M U T E 1 _ _ _ MUTE
M U T E 2 _ _ _ MUTE OFF
SURROUND
A C S U 0 _ _ _ SURROUND TOGGLE
A C S U 1 _ _ _ SURROUND NORMAL
A C S U 2 _ _ _ SURROUND OFF
A C S U 4 _ _ _ SURROUND 3D HALL
A C S U 5 _ _ _ SURROUND 3D MOVIE
ACSU6 _ _ _
SURROUND 3D
STANDARD
ACSU7 _ _ _
SURROUND 3D
STADIUM
AUDIO
CHANGE
A C H A _ _ _ _ TOGGLE
SLEEP TIMER
OF TM0 _ _ _OFF
O F T M 1 _ _ _ SLEEP TIMER 30 MIN
O F T M 2 _ _ _ SLEEP TIMER 1 HOUR
OF TM3 _ _ _
SLEEP TIMER 1 HOUR
30 MIN
O F T M 4 _ _ _ SLEEP TIMER 2 HOUR
OF TM5 _ _ _
SLEEP TIMER 2 HOUR
30 MIN
3D
T D C H 0 _ _ _ 3D OFF
TDCH1_ __
2D s 3D
T D C H 2 _ _ _ SIDE BY SIDE
T D C H 3 _ _ _ TOP AND BOTTOM
TDCH4_ __
3D s 2D (SIDE BY SIDE)
TDCH5_ __
3D s 2D (TOP AND
BOTTOM)
T D C H 6 _ _ _ 3D AUTO
TDCH7_ __
3D s 2D*
1
DEVICE NAME T V N M 1 _ _ _
DISPLAY THE DEVICE
NAME
SOFTWARE
VERSION
SWV N 1 _ _ _
DISPLAY THE
SOFTWARE VERSION
IP PROTOCOL
VERSION
IPPV1
DISPLAY THE IP
PROTOCOL VERSION
*1
These commands are available only during 3D mode.
NOTE
• If an underbar (_) appears in the parameter column, enter a
space.
• If an asterisk (*) appears, enter a value in the range indicated
in brackets under CONTROL CONTENTS.
Connecting a PC
