Sharp LCD colour TV - Dimensional Drawings (LC-70 UD1 H Model)

88
Dimensional drawings
LC-70UD1H
1578
1539*
1
866*
1
538
996
950
700
56*
2
114*
3
160
374
200
400
400
Appendix
Unit : mm
