Sharp LCD colour TV - Dimensional Drawings (LC-60 UD1 H Model)

89
LC-60UD1H
748
*1
480
1331
*1
876 829
1378
160
374
400
400
200
700
56
*2
114
*3
*1
Active area
*2
Thinnest part
*3
Including projecting parts
NOTE
• Dimensions do not include protrusions such as screws and some parts.
Unit : mm
