Before turning on the power
Notes on installing the TV
• Avoid direct sunlight and place the TV in a well-ventilated location.
• Place the TV in a level location.
• Do not turn on the power of the TV before connecting the AC cord.
1 Connecting the antenna cable.
To enjoy a clearer picture, use an outdoor antenna. The following is a brief explanation of the types of connections that are used
for coaxial cable.
Standard DIN45325
plug (IEC169-2)
75-ohm coaxial cable
(round cable)
Antenna cable
(commercially available)
Room antenna terminal
(75-ohm type)
To antenna
terminal
or
2 Connecting external devices.
See pages 26 to 29 for connecting external equipment, such as a VCR and DVD player.
3 Plug the AC cord into the AC outlet.
TV (rear view)
AC cord
AC outlet
• Place the TV close to the AC outlet, and keep the power plug within reach.
• Disconnect the AC cord from the AC outlet if the TV will not be used for a long period of time.
4 Bundling the cables.
As the picture illustrated, insert the cable clip into the hole on the TV, and put the cable into the cable clip for
banding.
CAUTION
• TO PREVENT RISK OF ELECTRIC SHOCK, DO NOT TOUCH UN-INSULATED PARTS OF ANY CABLES WITH THE AC
CORD CONNECTED.
Preparation
