6-19
TROUBLESHOOTINGâ–ºPAPER JAM
Misfeed in the fusing area B
1
Lift the fusing unit pressure adjusting levers to
allow easier removal.
2
Remove the misfed paper.
Be careful not to tear the misfed paper during removal.
The fusing unit is hot. Do not touch the fusing unit when removing misfed paper. Doing so may cause a burn or
injury.
• When removing misfed paper, do not touch or damage the photoconductive drum and the transfer roller.
• Be careful about unfixed toner on the misfed paper not to soil your hands or clothes.
3
If the misfed paper cannot be removed, remove
the paper by pulling it into the paper output
area.
Be careful not to tear the misfed paper during removal.
4
Lower the fusing unit pressure adjusting levers, to return them to their
operating positions.
Fusing unit pressure adjusting levers
To Next Page
