GENERAL INFORMATION
PART NAMES AND FUNCTIONS
!1 Developer unit
Pull out to add toner.
!2 Toner hopper
Contains toner.
!3 Fusing unit
The fusing unit is hot. Exercise care in this area.
!4 Developer unit lock lever
Pull down to release the developer unit.
!5 Release lever
Press to release the upper half of the copier.
!6 Photoconductive drum
Copy images are formed on the photoconductive
drum.
Accessories
Operation manual . . . . . . . . . . . . . . . . . . . . 1
Part names and functions
