Sharp SF-1116 - Using the Multi Bypass Feeder

63
OPTIONAL EQUIPMENT
MULTI BYPASS FEEDER (SF-MF15)
1
Unfold the multi bypass feeder.
●
When feeding A4R, B4, or A3 (8-1/2" x 11"R, 8-1/2" x 14", or
11" x 17") sized paper, extend the feeder tray.
2
Set the paper guides to the copy paper width.
●
A6 sized paper must be fed narrow side into the feed slot.
3
Insert the copy paper all the way into the multi bypass
feeder.
●
Up to 50 sheets of standard copy paper measuring from A6 to
A3 (5-1/2" x 8-1/2" to 11" x 17") can be loaded in the multi bypass
feeder.
●
Transparency film, labels, tracing paper, and other special
purpose papers must be fed individually.
●
When adding paper, first remove remaining paper, combine it
with the paper to be added and then reload as a single stack.
Using the multi bypass feeder
Multi bypass feeder (SF-MF15)
