OPTIONAL EQUIPMENT
MULTI BYPASS FEEDER (SF-MF15)
The multi bypass feeder automatically feeds up to 50 sheets of
standard copy paper.
Acceptable copy (Automatic feed)
paper Weight: 56 to 80 g/m
2
(15 to 21 lbs.)
Size: A6 to A3 (5-1/2" x 8-1/2" to 11" x 17")
Capacity: Up to 50 sheets, provided the total
aggregate thickness does not exceed
5 mm (3/16")
(Single sheet feed)
Weight: 52 to 128 g/m
2
(14 to 34 lbs.)
Size: A6 to A3 (5-1/2" x 8-1/2" to 11" x 17")
A4 (8-1/2" x 11") is the maximum size for
paper weighing from 104 to 128 g/m
2
(28 to 34 lbs.).
Weight Approx. 2 kg (4.5 lbs.)
Dimensions 350 mm (W) x 493 mm (D) x 185 mm (H)
(13-25/32" (W) x 19-27/64" (D) x 7-19/64" (H))
Power supply Drawn from the copier
Specifications are subject to change for improvement without notice.
Specifications
Paper guides
Multi bypass feeder (SF-MF15)
