3. Raise or lower the stabilizer legs to allow
drive ram I-beam full contact with the
ground. Make sure the Post Driver is
stable.
NOTE: On units without stabilizer legs, store
the unit against a post driven into the ground.
Position the unit with the driving ram next to
the post and secure with a chain wrapped
securely around the post and Post Driver.
On hydraulic tilt Post Drivers, to
prevent the forward tilt cylinder from
drifting, tighten the bolt and nut on
the cylinder stop bracket. Failure to
tighten this bolt and nut could allow the
dismounted Post Driver to fall over, causing
serious injury or even death.
4. On hydraulic tilt Post Drivers, tighten the
nut on cylinder stop bracket bolt (F11) to
prevent the cylinder from drifting and
causing an unstable condition with the Post
Driver.
(F11) Cylinder Stop Bolt.
5. Make sure all pressure is released
(zero pressure) from the Post Driver
hydraulic system. Disconnect hydraulic
pressure supply hose (G17) from the
tractor. Disconnect hydraulic return hose
(G20) from the tractor.
(G17) Hydraulic Pressure Supply Hose. (G20) Hydraulic
Return Hose. (G1 or H1) Control Valve.
6. Remove top link pin (B8) from weldment
(K1) and disconnect three-point hitch top
link. Disconnect the two lower lift arms
from the three-point hitch weldment to
separate the tractor three-point hitch from
the Post Driver.
7. Carefully move the tractor or power source
away from the Post Driver.
Failure to tighten this bolt could allow the Post
Driver to fall over, causing serious injury or
even death.
