Driver Assembly
HD-10 Service Parts - Driver Assembly
Item No. Part No. Description Qty.
A1 SM-1011-DRC Driving Ram Complete 1
SM-1011-DRO Driving Ram Only 1
A2 SM-00512 Guide Block Pkg. of 4
A3 SM-0933-(18 ga) Shim 4
SM-9034-(14 ga)
SM-0935-(10 ga)
A4 SM-1011-G Rubber Debris Guard
1
1
A5 Guard Mounting Strap 1
L8 Caution Tag 1
A7 Guard Mounting Bolt 3
A8 Guard Mounting Washer 3
A9 Guard Mounting Nut 3
A11 SM-1011-SBU Upper Spring Bracket 1
B1 SM-10412 Main Carriage Channel 1
B2 SM-1041-RLB Road Lock Bracket 1
(no pin)
B3 SM-0041-B Rubber Bumper
2
4
B4 Bumper Lock Washer, 5/16 4
B5 Bumper Nut, 5/16-18 4
B6 SM-093 Road Lock Bracket Bolt 2
B7 SM-932 Road Lock Bracket Nut 2
B8 SM-1041-RLP Road Lock Pin 1
B9 SM-1041-RLC Road Lock Pin Clip 1
C1 SM-1026 Cylinder Assembly 1
C2 SM-10261 Cylinder Tube 1
C3 SM-10266 Cylinder Piston/Rod 1
C4 SM-10267 Piston Self-Locking Nut 1
C5 SM-018 Cylinder Nut 1
(with setscrew)
C6 SM-10268 Lock Washer 1
C7 SM-10262-D Cylinder Cap 1
(with seal)
HD-10 Service Parts - Driver Assembly (continued)
Item No. Part No. Description Qty.
C8 — Bolts, Lock Washers, Nuts 2
(upper spring bracket)
C12 SM-0931 Lower Bracket Lock Nut 2
C13 SM-1011-SBL Lower Spring Bracket 1
C14 SM-1011-DRS Spring 2
(with spring clips installed)
C15 SM-1011-SC Spring Clip Only 4
D3 S-012 Short Bracket Bolts 4
5/8-11 x 1-1/4
D4 S-013 Short Bracket Lock Washer, 5/8 4
D5 — Short Bracket Nut, 5/8-11 4
J1 ODMAN Document Storage Tube 1
L2 MS-161 Large “SHAVER” Decal 1
L3 MS-169 Control Valve Decal 1
L5 MS-181 Pinch Area Warning Decal 1
L7 MS-280 FEMA Member Decal 1
L9 MS-180 Cylinder Shaft Loose Decal 1
(not visible)
1
SM-1011-G Includes Items A4, A5, L8, A7, A8, and A9.
2
SM-1041-B Includes Items B3, B4, and B5.
Drive Ram Weldment Parts
HD-10 Service Parts - Drive Ram Weldment
Item No. Part No. Description Qty.
A10 SM-1011-BS Guide Pins
1
4
A12 SM-1011-LYB Lift Yoke Bar
1
1
A13 SM-1011-LYTS Lift Yoke Top
1
1
1
Replacement of these parts requires removal of old parts with a cutting torch and/or
grinding wheel. New (replacement) parts must be welded to drive ram. This type of
repair voids any warranties.
