Manual Base Plate Assembly
HD-10 Service Parts - Manual Base Plate Assembly
Item No. Part No. Description Qty.
D1 SM-101 Short Channel (manual) 1 D6 SM-014 Channel Mounting Pin 2 D7 SM-2025-LP Lynch Pin 4 E1 SM-1015-BPC Complete Base Plate Assembly
1
1
E2 SM-1015 Manual Base Plate 1 E3 SM-016 Side Tilt Crank 1 E4 S-20 Flat Washer 1 E5 SM-017 Side Tilt Crank Sleeve 1 E6 SM-018 Side Tilt Crank Nut 1
(with setscrew)
E7 SM-2025-SB Side Tilt Crank Screw Block 1 E8 — Screw Block Mounting Bolt, 1
5/16-18 x 3”
E9 — Screw Block Lock Washer, 5/16 1 E10 — Screw Block Mounting Nut, 1
5/16-18
E11 SM-019 Forward Tilt Crank 1 E12 SM-021 Forward Tilt Nut (with setscrew)
2
1
E13 SM-022 End Tilt Tee 1
HD-10 Service Parts - Manual Base Plate Assembly (continued)
Item No. Part No. Description Qty.
E14 — Base Plate Mounting Bolt, 4
5/8-11 x 1-1/2
3
E15 — Base Plate Flat Washer, 5/8
3
4
E16 — Base Plate Lock Washer, 5/8
3
4
E17 — Base Plate Mounting Nut, 4
5/8-13
3
E18 SM-015-CC Crank Handle Cover 2 E19 SM-2025-SBS Crank Screw Block Support 1 G1 P-20 Hydraulic Control Valve 1
P-2012 Seal Kit for P-20 Valve, 1
not shown
G2 — Valve Mounting Bolt, 3
5/16-18 x 3
G3 — Valve Mounting Washer, 5/16 3 G4 — Valve Mounting Nut, 5/16-18 3
1
Includes Short Channel, Pins, Cranks, Stops, etc.
2
Or S-095 Nut (with setscrew).
3
S-1092 Kit Includes Items E14, E15, E16, and E17.
NOTE: All hardware is Grade 5.
