Hydraulic Base Plate Assembly
HD-10-H Service Parts - Hydraulic Base Plate Assembly
Item No. Part No. Description Qty.
D2 HBP-909 Short Channel (hydraulic)
1
1
D6 SM-014 Channel Mounting Pin 2 D7 SM-2025-LP Lynch Pin 10 E14 — Base Plate Mounting Bolt, 4
5/8-11 x 1-1/2
3
E15 — Base Plate Flat Washer, 5/8
3
4
E16 — Base Plate Lock Washer, 5/8
3
4
E17 — Base Plate Mounting Nut, 4
5/8-11
3
F1 HD-10-HCK Hydraulic Conversion Kit
1
1
F2 HBP-91011 Hydraulic Base Plate 1 F3/F4 HBP-908120 Cylinder Kit Complete
2
1
F3 HBP-90812 Forward Tilt Cylinder 1 F4 HBP-90813 Side Tilt Cylinder 1 F5 HBP-908131 Cylinder Seal Kit, not shown 1 F7 HBP-908133 Cylinder Mounting Pin 2 F8 HBP-908134 Side Tilt Mounting Pin 1
HD-10-H Service Parts - Hydraulic Base Plate Assembly (continued)
Item No. Part No. Description Qty.
F9 — Cylinder Stop Plate, 8.5
2, 4
1
F10 — Cylinder Stop Plate, 10.5
2, 4
1
F11 — Cylinder Stop Bolt, 1
1/2-13 x 1-3/4
2, 4
F12 — Cylinder Stop Lock Washer, 1/2
2, 4
1
F13 — Cylinder Stop Nut, 1/2-13
2, 4
1
H1 P-23 Hydraulic Control Valve 1 — P-2312 Seal Kit for P-23 Valve, 3
not shown
H2 — Valve Mounting Bolt, 5/16-18 x 3 3 H3 — Valve Mounting Washer, 5/16 3 H4 — Valve Mounting Nut, 5/16-18 3 H5 SM-02111-P Tilt Cylinder Hose 4 L10 MS-171 High-Pressure Warning Decal 2
1
HD-10-HCK Kit Includes Items D2, F2, and F3/F4.
2
HBP-908120 Kit Includes Items F3, F4, and F9 Through F13.
3
S-1092 Kit Includes Items E14, E15, E16, and E17.
4
HBP-908-CS Kit Contains Items F9, F10, F11, F12, and F13.
NOTE: All hardware is Grade 5.
