Shaw SDHmini - 2 Important Information; Symbols Table; Lithium-Ion Cell - Battery

The SDHmini sengs can be adjusted by a user-friendly soware interface
incorporang mulple menus, hot key combinaons, informaon displays and
control funcons.
Use the supplied USB cable, aach between the PC and the instrument, an
automac connecon over USB is established.
The USB port allows:
● Charging of the baery (Li-ion) when connected to PC or dedicated
power supply
● Downloading of new rmware to the unit
● Downloading of setup data from dedicated PC soware
The view panel allows access to many of the features, sengs and informaon
pages within the instrument.
A micro SD card is ed to the instrument, the contents of which can be explored
by clicking the SD card icon in the boom le of the view panel. The contents may
include user manuals, service notes, calibraon data sheets, rmware backups etc.
2 Important Informaon
2.1 Symbols Table
6
2.2 Lithium-ion Cell - Baery
The SDHmini is powered by a single lithium-ion cell. The cell is not
eld replaceable by the user as it is completely enclosed within the
instrument. However, the cell may be exchanged by an authorised
agent who has received the necessary training, support systems
and accreditaon. It is recommended to only use the USB power
supply supplied with the instrument.
It is recommended that the SDHmini be put on charge overnight
when the unit is rst received.
To aain maximum cell life, the SDHmini should always be charged
at room temperature. The discharging cell life (hours of use from a
fully charged cell) will reduce when used in cold condions. Switch
on the instrument to check if fully charged.
The symbol indicates that the device contains a baery which may
be charged via the USB connector.
Rang of instrument is less than 1 W in operaon. Charging
voltage is 5 V nominal.
