Shaw SDHmini - Piping Installation Schematic

The SDHmini should be placed on a stable surface prior to connecng to the
sample pipework. Care should be taken to ensure that the sample presented to the
SDHmini is not contaminated with any component that will damage, contaminate
or aect in a way that will impair the unit’s accuracy.
The ow rate, although not crical to the sensor measurement, should be low
enough to avoid abrasion to the sensor surface without being so low as to extend
the SDHmini response me to an unacceptable level. In general, a ow rate of
between 2 and 5 litres/min at normal temperature and pressure will give the right
balance.
The SDHmini is designed to operate at atmospheric pressure with a maximum of
0.3 bar.
3.3 Piping Installaon Schemac
8
MAIN
PROCESS
LINE
1
3
2
4
5
6
7
8
9
a.
b.
The sample point should be on the upper surface of the horizontal
pipe or from a vercal secon of pipe, wherever possible.
The sample tube should run upwards from the sample point. If
this is not possible, then an inspecon port or drain tap should be
installed at the lowest point in the sample system.
Notes
