12
removing/installing the engine
450 SEF-R
❱❘ INSTALLING THE ENGINE IN THE FRAME
• Position the motor within the frame.
• Position the swing arm.
• Set the engine axes.
• Tighten the motor axes to 40 Nm.
• Tighten the swing arm pivot to 100 Nm.
• Set the frame guards and secure them with clamps.
• Put the right and left cylinder head supports. Put red thread lock and tighten to 25 Nm.
• Fit the left radiator and tighten to 10 Nm.
• Place the cooling hoses
• Make sure the engine is clean and place back the clutch receiver. Tighten to 10 Nm.
• Place the secondary chain and adjust the tension (see procedure on the user manual).
• Put the chain guard.
• Put the throttle body.
• Put the pencil coil.
• Put the exhaust pipe and secure it to the cylinder with its two springs.
• Reconnect the entire harness connected to the engine
(starter case, TPS, water temperature sensor, pencil coil and injector).
• Reinstall the tank along with its vents (refer to the user manual).
• Reconnect the battery (refer to the user manual).
WARNING
Before reconnecting, check that the ignition key (SEF 450 standard) or the switch (450 SEF / R racing) is in the «OFF» position.
• Place back the saddle.
• Fill coolant and engine oil (refer to the user manual).
