43
1
ENGLISH
Changing the TPS - Throttle Position Sensor
The TPS of the throttle body monitors the position of
the throttle. Its indexing is paramount to the proper
functioning of the motorcycle.
If you replace it, follow this procedure.
Unscrew the screw (1) and remove the TPS.
Position the new TPS and the screw (1) without
tightening it.
Connect the motorcycle and run the Exxotest
diagnostic software (see procedure below).
Click on the Diagnostics menu logo
Then click Sherco M3C Measuring parameters Throttle position
Adjust the sensor position by rotating it (see
picture) until the displayed value is set to 0.5V +/-
0.05.
Once done tighten the screw (1) to 4 Nm +/-0.7.
