18
450 SEF-R
❱❘ Removing the clutch bellhousing
• Remove the finger follower from the clutch hub
• Flatten the safety tab.
• Block the clutch hub using the 5749 and uns-
crew the nut.
• Remove the hub, the notched washer and the
bellhousing.
• Remove the drive pinion of the oil pump if it
does has not remained stuck to the bellhousing.
• Check the needle bearings and change them if
necessary
• Visually check the clutch bellhousing.
WARNING
If you want to dismount the freewheel or the balancer
shaft further on, block the primary drive with the
tool 5593. Unlock the nut off the mass of the balancer
shaft (2).
1
2
❱❘ DRemoving the water pump oil seal
and the bearing
• Remove the water pump turbine with a 10 soc-
ket by unscrewing it while holding the drive pinion.
• Remove the water pump shaft. Both oil seals
have been made accessible.
WARNING
The 2 seals are not identical
nor are they interchangeable.
• Disconnect the shaft from the water pump
drive pinion.
• Remove the water pump bearing.
REMOVING THE ENGINE
