4-46 Control output 1 soft start time setting screen
Initial value: oFF
Setting range: oFF, 1 – 120 (seconds)
Sets soft start time that gradually changes output.
Does not function if oFF is set.
For details, see 8-6.
4-47 Output 2 proportional cycling time setting screen
Initial value: Contact output: 30 (seconds),
SSR drive voltage output: 3 (seconds)
Setting range: 1 – 120 (seconds)
Sets control output 2 proportional cycling time.
Not displayed when output type is voltage or current.
4-48 Control output 2 characteristics setting screen
Initial value: rA ()
Setting range: rA, dA ()
Sets characteristics of control output.
(RA) : Reverse characteristics (for heating)
(DA) : Direct characteristics (for cooling)
Displayed if Y, I, P, V is selected for control output 2.
4-49 Control output 2 soft start time setting screen
Initial value: oFF
Setting range: oFF, 1 – 120 (seconds)
Sets soft start time that gradually changes output.
Does not function if oFF is set.
For details, see 8-6.
Displayed if Y, I, P, V is selected for control output 2.
4-50 SV limiter lower limit setting screen
Initial value: Lower limit value of measuring range
Setting range: Lower limit value of measuring range to higher
limit value of measuring range - 1 count
If using setting range of target values below measuring range:
Set lower limit value.
(Able to prevent incorrect setting in danger range, etc.)
4-51 SV limiter higher limit setting screen
Initial value: Higher limit value of measuring range
Setting range: Higher limit value of measuring range to lower
limit value of SV limiter + 1 count
If using setting range of target values below measuring range:
Sets higher limit value.
(Able to prevent incorrect setting in danger range, etc.)
If Sc_L/Sc_H are changed, the respective values are set for
SV_L/SV_H.
4-52 Number of patterns setting screen
(programming function only)
Initial value: 4
Setting range: 1, 2, 4
Sets number of patterns used by programming function.
4-53 Time unit setting screen (programming function only)
Initial value: Hm (
)
Setting range: Hm, mS (
)
Sets time unit used by programming function.
Hm: Hour/minute, mS: Minute/second
4-54 PV bias value setting screen
Initial value: 0 (unit)
Setting range: -1999 – 2000 (unit)
Used for compensating input error of sensors, etc.
When bias is applied, control is also executed according to the
compensated value.
4-55 PV gain compensation value setting screen
Initial value: 0.00 (%)
Setting range: -5.00 – 5.00 (%)
Used for compensating input gain error of sensors, etc.
When gain compensation is applied, control is also executed
according to the compensated value.
4-56 PV filter time setting screen
Initial value: 0 (seconds)
Setting range: 0 – 9999 (seconds)
Used to alleviate the effect if input varies radically or
noise is superimposed.
Filter does not function if set to 0 seconds.
4-57 Measuring range code setting screen
Initial value: Multi: 05, voltage: 86
Setting range: Selected from “Chapter 7: Measuring Range
Codes.”
Combination of input type and measuring range is set by the code.
Setting cannot be changed during control action.
4-58 Input unit setting screen
Initial value: c ()
Setting range: c, F ()
Temperature unit for sensor input is set to C (°C) or F (°F).
Not displayed if linear input (mV, V, mA) is selected.
K(
) is displayed if measuring range code is 15 – 18 (in kelvin).
Modification of unit is only possible when in standby mode.
4-59 Input scaling lower limit value setting screen
Initial value: 0.0 (unit)
Setting range: -1999 – 9989 (unit)
Sets scaling lower limit value for linear input (mV, V).
Cannot be set by monitoring screen for sensor input.
4-60 Input scaling higher limit value setting screen
Initial value: 100.0
Setting range: (Sc_L setting value) + 10 – (Sc_L setting value)
+ 10,000
Sets scaling higher limit value for linear input (mV, V).
Cannot be set by monitoring screen for sensor input.
4-61 Input decimal point position setting screen
Initial value: 1 digit following decimal point (0.0)
Setting range: No decimal point (0) – 3 digits following
decimal point (0.000)
Sets decimal point position for input scaling.
Cannot be set by monitoring screen for sensor input.
To 4-0 screen
Note: For SV limiter setting, the lower limit value is given
preference when SV limiter lower limit value is less than
higher limit value. Consequently, higher limit cannot be
set less than lower limit value + 1 count.
Note: If the difference between the higher limit value and
lower limit value is less than +10 count or higher than
+10,000 count, the higher limit value is automatically
changed to + 10 count or +10,000 count. The higher
limit value cannot be set less than lower limit value +10
count or higher than +10,000 count.
To 4-54 screen
Note: Setting cannot be changed during control action on
4-57 – 4-61 screen. Change setting with standby
mode on 0-1 screen.
If the setting is modified, all data related to measuring
range will be initialized.
