Screen No. Parameter (item)/screen Initial value Setting/selection Record
2-9 OUT2 PID P
2_P3 (

)

2-10 OUT2 hysteresis
2dF3 (

)

2-11 OUT2 PID I
2_i3 (

)

2-12 OUT2 PID D
2_d3 (

)

2-13 OUT2 dead band
2db3 (

)

2-14 OUT2 PID target value function
2SF3 (

)

2-15 OUT2 lower limit limiter
2oL3 (

)

2-16 OUT2 higher limit limiter
2oH3 (

)

4-0 Initial screen
init (

)

4-1 Key lock setting
LocK (

)

4-2 Event 1 type
E1_m (

)

4-3 Event 1 hysteresis
E1_d (

)

4-4 Event 1 standby action
E1_i (

)

4-5 Event 1 latching
E1_L (

)

4-6 Event 1 output characteristics
E1_A (

)

4-7 Event 2 type
E2-m (

)

4-8 Event 2 hysteresis
E2-d (

)

4-9 Event 2 standby action
E2-i (

)

4-10 Event 2 latching
E1_L (

)

4-11 Event 2 output characteristics
E1_A (

)

4-12 Event 3 type
E3-m (

)

4-13 Event 3 hysteresis
E3-d (

)

4-14 Event 3 standby action
E3-i (

)

4-15 Event 3 latching
E3_L (

)

4-16 Event 3 output characteristics
E3_A (

)

4-17 HB1 break/loop alarm mode
Hbm1 (

)

4-18 HB1 break alarm setting
C1Hb (

)

4-19 HB1 loop alarm setting
C1HL (

)

4-20 HB2 break/loop alarm mode
Hbm2 (

)

4-21 HB2 break alarm setting
C2Hb (

)

4-22 HB2 loop alarm setting
C2HL (

)

4-23 Analog output type
Ao_m (

)

4-24 Analog output scaling lower limit
Ao_L (

)

4-25 Analog output scaling higher limit
Ao_H (

)

4-26 Analog output limiter lower limit
AL_L (

)

4-27 Analog output limiter higher limit
AL_H (

)

4-28 DI1 mode
D1_m (

)

4-29 DI2 mode
D2_m (

)

4-30 DI3 mode
D3_m (

)

4-31 DI4 mode
D4_m (

)

4-32 Communication mode setting
comm (

)

4-33 Communication address
Addr (

)
4-34 Communication data format
dAtA (

)

4-35 Start character
SchA (

)

4-36 BCC operation/protocol type
ChK (

)

4-37 Communication speed
bPS (

)

4-38 Communication delay time
dely (

)

4-39 Communication memory mode
mem (

)

4-40 Communication master mode
mS_m (

)

4-41 Start slave address
S_Ad (

)
4-42 End slave address
E_Ad (

)
4-43 Write-in data address
writ (

)

4-44 Output 1 proportional cycling time
o_C1 (

) Y:

, P:
4-45 Output 1 output characteristics
Act1 (

)

4-46 Output 1 soft start time
SoF1 (

)

4-47 Output 2 proportional cycling time
o_C2 (

) Y:

, P:
4-48 Output 2 output characteristics
Act2 (

)

4-49 Output 2 soft start time
SoF2 (

)

4-50 SV limiter lower limit value
SV_L (

)

4-51 SV limiter higher limit value
SV_H (

)

4-52 Number of patterns setting
Ptnc (

)
4-53 Time unit
t_Un (

)

4-54 PV bias value
PV_b (

)

4-55 PV gain compensation
PV_G (

)

4-56 PV filter time
PV_F (

)
4-57 Measuring range code
rAnG (

) Multi:

V :

4-58 Input temperature unit
Unit (

)
4-59 Input scaling lower limit Sc_L ( ) 
4-60 Input scaling higher limit Sc_H ( ) 
4-61 Input scaling decimal point position dP ( ) 
