Shimadzu RID-10A - 4.6 Connecting Recorder and Integrator

1. Connection with recorder
Connect the RECORDER terminal of the RID-1OA and the
recorder using the supplied
signal cable.
Recorde-
-t RID - 1OA
[ Tk15th terminal of RID - 1OA
Recorder
Recorder
Recorder GND
(1 OmV full scale recorder)
or the 6th terminal
(I mV full scale recorder)
The 7th terminal
of RID - 1OA
Green
~
Green
' Grounding terminal
When using a stranded wire, twist the end tightly, or tin it with
solder.
Using a small screwdriver or other tool, depress the rectangular
button adjacent to the appropriate terminal hole. Insert the wire and
release the button to
clamp the wire in position, as shown in the
flapre below.
Wire
-
Press
4 - 1 1
RID - 1OA -
