12. Connections and Communications with External Equipment
2
4
1
3
5
6
7
11
13
12
8
9
10
14
(3) Data format in case of “oL” or “-oL” (Overload)
The below is the data format for “oL”.
Data length of this example: 12 bytes
Position 1 2 3 4 5 6 7 8 9 10 11 12
ASCII
code
20H 20H 20H 20H 20H 4FH 4CH 20H 20H 20H 20H 0DH
Data O L C/R
For “-oL” (negative overload), Position 1 is replaced with “-” (minus, ASCII code: 2DH).
The following parts appearing in “(2) Information of additional bytes” also apply to (3).
(i) Output with stability information
(ii) When the delimiter “C/R+L/F” is selected, (Menu item No
96
, Refer to 12.3.7.)
