12. Connections and Communications with External Equipment
2
4
1
3
5
6
7
11
13
12
8
9
10
14
(3) Echo back command
The balance again transmits the character strings of N pieces included between an echo back
command ‘{‘ or ’}’ and the delimiter. An unprocessed echo back command is not left in the receiving
buffer of the balance, N ≤ 30.
Example 5: {ABCDEFG12345<CR>
…After receiving this command, the balance outputs ABCDEFG12345<CR>.
When using the balance together with a printer, these text strings can be printed to the printer.
(Printing of arbitrary text strings)
Note
Only capital alphabets and a part of symbols (decimal point, symbol etc.)
can be used when printing with an electronic printer. A maximum of 15
characters per line.
(4) Command codes for Format EB type (menu item
77
) [F-PrEEb]) and Format Old EB type (menu item
78
)
(i) Commands related to output
D01 Continuous output*
D03 Continuous output with stability information*
D05 Single output
D06 Auto Print setting (type of Auto Print is set separately)
D07 Single output with stability information***
D09 Release of continuous output and Auto Print
(ii) Commands related to operation keys
POWER Equivalent to the [POWER] key.
Q Equivalent to the [POWER] key.
MENU Equivalent to the [CAL] key.
TARE Equivalent to the [O/T] key.
T Equivalent to the [O/T] key.
UNIT Equivalent to the [UNIT] key.
PRINT Equivalent to the [PRINT] key.
POWER+ Equivalent to holding the [POWER] key
MENU+ Equivalent to holding the [MENU] key
UN IT+ Equivalent to holding the [UNIT] key
PRIN T+ Equivalent to holding the [PRINT] key
RECALC Equivalent to the [RECALC] key of the AKB-301 Application Keyboard.
C Equivalent to the [C] key of the AKB-301 Application Keyboard.
*Not applicable to a verified balance as a legal measuring instrument in using region
**Handshake is “OFF” or “Hardware”
***Using a verified balance as a legal measuring instrument: Only output at stable.
(The balance continuausly outputs
every about 80ms**)
