2.2.4 Parts List (STM-1220)
Table 2-2：Parts List (STM-1220)
No. Name Part No. No. Name Part No.
1 Main power switch YE10010000000
24
Copper teflon pipe
connector 1/4H×1/4PT
BH12010400410
2 Door plate - 25
Copper ball core valve
1/4"
YY60001430000
3
Base plate of electric
components box
- 26
Copper pipe coupler
1/4''
BH12010400110
4 Fan with fan guard YM60922500100 27 Heating tank -
5
Electric components
box
- 28
Stainless steel ball
valve 3/8"
YW50030800100
6
HANYOUNG
controller
YE81100010000 29
Copper teflon pipe
connector 3/8H×3/8PT
BH12030800610
7
Electric control box
rear plate and caster
mounting plate
- 30 Microswitch* YE14152400000
8 Clapboard - 31 Float ball* -
9 Side plate - 32 Switch cover plate -
10
Pressure gauge fixing
plate
- 33 Cooling pipe -
11 Crossbeam - 34 Flat gasket 10 YW66102500000
12 Pressure gauge YW85001000100 35 Elastic gasket 10 YW65010000000
13 Rear plate mini cover - 36
Inner hexagon
cylindrical screw
M10×25
YW61102500000
14
Fixing plate of rear
plate mini cover
- 37 Oil cap BH12030403040
15 Rear plate - 38 Pipe heater cover BL80091000120
16
Plate cover fixing
plate
- 39 Pipe heater BH70122000050
17 Plate cover - 40 Coolling tank -
18
External thread
1/4PT×1/4H
- 41 Pump TP-150 BM20015000050
19 Water filter 1/2 YW57010200000 42 Pump flange -
20 Liquid level indicator 43
Inner hexagon
cylindrical screw
M10×30
YW61103000100
21 Set screws M12 YW68121000000 44 Copper tee joint 1/4"PT BH12010400010
22
3/8"PT×∅13 Copper
connector
BH12030801110 45
Copper teflon pipe
connector 3/8H×1/4PT
YW04030800400
23
Copper teflon pipe
connector
1/4H×1/4PT(L type)
YW04010400400 46
1/4" Stainless steel tee
joint
YW52010400000
