Shini STM Series User Manual

28(108)
2.2.6 Parts List (STM-2440)
Table 2-3：Parts List (STM-2440)
No. Name Part No. No. Name Part No.
1 Main power switch* YE10010000000
26 Water filter 1/2 YW57010200000
2 Door plate - 27
Rear plate mini cover and
mini cover fixing plate
-
3 Long gear lock YW00000000100 28 EGO protective box YR40000400300
4
Fixing plate of electric
components
- 29 Base plate -
5 Fan with fan guard YM60922500100 30 Float ball -
6
Thick head screw
M6×10
YW63061000000 31 Float ball cover plate -
7 Electric control box - 32 Switch cover plate -
8
HANYOUNG
controller
YE81100010000 33
Copper teflon pipe
connector 1/4H×1/4PT
BH12010400410
9 Side plate (right) -
34 Oil cap BH12030403040
10
Electric control box
rear plate
- 35 Copper ball core valve 1/4" YY60001430000
11
Inner hexagon
cylindrical screw
M8×16
YW60081600100 36 Copper pipe coupler 1/4'' BH12010400110
12 Clapboard - 37 Cooling pipe -
13
Pressure gauge fixing
plate
- 38
Copper teflon pipe
connector 3/8H×3/8PT
BH12030800610
14 Pressure gauge YW85001000100 39 Solenoid valve 3/8" YE32215400000
15
Thick head screw
M3×5
YW63030600000 40 Copper tee joint 3/8'' BH12030800010
16 Crossbeam - 41
Copper teflon pipe
connector 3/8H×3/8PT(L
typen)
YW04030800300
17 Fan guard YM60423000000 42 Copper connector 2 -
18 Fan guard YM60423000000 43
Copper teflon pipe
connector 1/4H×1/4PT(L
type)
YW04010400400
19 Rear plate - 44 Pipe heater* BH70244000050
20 Cover plate - 45 Elastic gasket 10 YW65010000000
21 Set screw M12 YW68121000000 46
Inner hexagon cylindrical
screw M10×25
YW61102500000
22 Liquid level indicator* - 47 Electric heating pipe shield BL80091000120
23
External
thread1/4PT×1/4H
- 48 Flat gasket 6 YW66061300000
24 Butterfly screwM6×15 YW69061500000 49 Screw M6 YW64000600300
25 Core 3/8"×1/2PT BH12131200010 50
Copper teflon pipe
connector 3/8H×1/4PT(L
type)
YW04030800200
