75(108)
2.3.34 Electrical Components List (STM-3650) (230V)
Table 2-18：Electrical Components List (STM-3650) (230V)
No. Symbol Name Specification Part No.
1 Q1 Circuit break 160A YE41161200000
2 - Excitation break away* 220VAC 50/60Hz YE40101600000
3 K1 Contactors* 230V 50/60Hz YE00602522000
4 K2~K4 Contactors** 230V 50/60Hz YE00503500000
5 F1 Overload relays 14~20A YE01260140000
6 F11 Fuse box** 32A 2P YE41032200000
7 - Fuse** 2A YE46002000100
8 S1 Thermocouple - -
9 S2 S3 Thermocouple - -
10 S4 Overheat protector* - -
11 S5 Limit switch 250V 5(4) YE14152400000
12
PC1 Circuit board** 100~240VAC 50/60Hz
13
A Control panel -
YE81100010000
14
X1 Terminal board -
YE61250040000
15 - Terminal board - YE61253500000
16 -
Terminal board
- YE61043500000
17 - Terminal board - YE61353500000
18 Y1 Solenoiud valve 230VAC 50/60Hz -
19 M1 Motor** 230V 50Hz 4.0kW -
20 EH1 EH2 Heater** 400V 50Hz 12kW -
21 FM1 FM2 Fan* 230VAC 50/60Hz -
* means possible broken parts.
** means easy broken part. and spare backup is suggested.
Please confirm the version of manual before placing the purchase order to guarantee that
the item number of the spare part is in accordance with the real object.
