2.3.9 Electrical Components List (STM-607~1220) (400V)
Table 2-7：Electrical Components List (STM-607) (400V)
No. Symbol Name Specification Part No.
1 Q1 Main switch* 16A YE10021160000
2 Q2 Circuit_breakers* 16A YE40601500000
3 - Excitation break away* - YE40023560000
4 K1 Contactors* 220V 50/60Hz YE00601521000
5 K2 Contactors** 220V 50/60Hz YE00601800000
6 F1 Overload relays 1.8~2.5A YE01160180000
7 F11 Fuse box** 32A 2P YE41032200000
8 - Fuse** 2A YE46002000100
9 F12 Fuse** 2A YE41001000000
10 T Transformer 500mA YE70402300800
11 S1 Thermocouple - -
12 S2 S3 Thermocouple - -
13 S4 Overheat protector* - -
14 S5 Limit switch 250V 5(4) YE14152400000
15
PC1 Circuit board** 100~240VAC 50/60Hz
16
A Control panel -
YE81100010000
17
X1 Terminal board -
YE61250040000
18 - Terminal board - YE61253500000
19 M1 Motor** 400V 50Hz 0.5kW -
20 EH Heater** 400V 50Hz 6kW -
21 FM Fan* 230VAC 50/60Hz -
* means possible broken parts.
** means easy broken part. and spare backup is suggested.
Please confirm the version of manual before placing the purchase order to guarantee that
the item number of the spare part is in accordance with the real object.
To Next Page
