39(108)
2.3.5 Electrical Components List (STM-607/910-D) (400V)
Table 2-5：Electrical Components List (STM-607-D) (400V)
No. Symbol Name Specification Part No.
1 Q1 Main switch* 32A YE10323200000
2 Q2 Q3 Circuit_breakers* 16A YE40601500000
3 - Excitation break away* 230V 50/60Hz YE40023560000
4 K1 K2 Contactors* 220V 50/60Hz YE00601521000
5 K3 K4 Contactors** 220V 50/60Hz YE00601800000
6 F1 F2 Overload relays 1.8~2.5A YE01160180000
7 F11 Fuse box** 32A 2P YE41032200000
8 - Fuse** 2A YE46002000100
9 F12 Fuse** 2A YE41001000000
10 T Transformer** 500mA YE70402300800
11 S1 S6 Thermocouple - -
12 S2 S3 S7 S8 Thermocouple - -
13 S4 S9 Overheat protector * - -
14 S5 S10 Hydrailic switch - YE14152400000
15 PC1 PC2 Circuit board** 100~240VAC 50/60Hz
16 A1 A2 Control panel -
YE80000100000
17
Y1 Y2 Solenoid valve* 230VAC 50/60Hz
-
18 X1 Terminal board - YE61250040000
19
-
Terminal board - YE61253500000
20 - Terminal board - YE61060000000
21
- Terminal board - YE61063500000
22 M1 M2 Motor** 400V 50Hz 0.5kW -
23 EH1 EH2 Heater** 400V 50Hz 6kW -
24 FM Fan* 230VAC 50/60Hz -
* means possible broken parts.
** means easy broken part. and spare backup is suggested.
Please confirm the version of manual before placing the purchase order to guarantee that
the item number of the spare part is in accordance with the real object.
