2.3.26 Electrical Components List (STM-607~1220) (230V)
Table 2-14：Electrical Components List (STM-607) (230V)
No. Symbol Name Specification Part No.
1 Q1 Main switch* 25A YE10125250000
2 Q2 Circuit_breakers* 25A YE40602500000
3 - Excitation break away* - YE40023560000
4 K1 Contactors* 230V 50/60Hz YE00601521000
5 K2 Contactors** 230V 50/60Hz YE00602522000
6 F1 Overload relays 2.8~4A YE01160280000
7 F11 Fuse box** 32A 2P YE41032200000
8 - Fuse** 2A YE46002000100
9 S1 Thermocouple - -
10 S2 S3 Thermocouple - -
11 S4 Overheat protector* - -
12 S5 Limit switch 250V 5(4) YE14152400000
13
PC1 Circuit board** 100~240VAC 50/60Hz
14
A Control panel -
YE81100010000
15
X1 Terminal board -
YE61250040000
16 - Terminal board - YE61253500000
17 -
Terminal board -
YE61040000000
18 - Terminal board - YE61043500000
19 Y1 Solenoid valve 230VAC 50/60Hz -
20 M1 Motor** 230V 50Hz 0.55kW -
21 EH Heater** 230V 50Hz 6kW -
22 FM Fan* 230VAC 50/60Hz -
* means possible broken parts.
** means easy broken part. and spare backup is suggested.
Please confirm the version of manual before placing the purchase order to guarantee that
the item number of the spare part is in accordance with the real object.
