2.2.8 Parts List (STM-3650)
Table 2-4：Parts List (STM-3650)
No. Name Part No. No. Name Part No.
1 Main power switch * YE41109000000
27 Water filter 1/2 YW57010200000
2 Door plate - 28
Rear plate mini cover and
mini cover fixing plate
-
3 Long gear lock YW00000000100 29 EGO protective box YR40000400300
4
Base plate of electric
components box
- 30 Base plate -
5
M6×15 Lentil-headed
screw
YW63061500000 31 Float ball -
6
M6×10 Lentil-headed
screw
YW63061000000 32 Float ball cover plate -
7 Fan with fan guard YM60922500100 33 Switch cover plate -
8 Electric control box -
34
Copper teflon pipe connector
1/4H×1/4PT
BH12010400410
9 HANYOUNG controller YE81100010000 35 Oil cap BH12030403040
10 Side plate (right) - 36 Copper ball core valve 1/4" YY60001430000
11
Electric control box rear
plate
- 37 Copper pipe coupler 1/4'' BH12010400110
12
M8×16 Inner hexagon
screw
YW61081600000 38
Copper teflon pipe connector
3/8H×3/8PT
BH12030800610
13 Clapboard - 39 Solenoid valve 3/8"* YE32215400000
14
Pressure gauge fixing
plate
- 40 Cooling pipe -
15 Pressure gauge YW85001000100 41 3/8'' Pipe coupler BH12030800110
16
Thick head screw
M3×5
YW63030600000 42 Pipe heater unit BH70365000050
17 Crossbeam - 43
Inner hexagon cylindrical
screw M10×25
YW61102500000
18 Fan with fan guard YM60423000000 44 Electric heating pipe shield BL80091000120
19 Cover plate - 45 Flat gasket 6 YW66061300000
20 Rear plate - 46 Screw M6 YW64000600300
21 Set screw M12 YW68121000000 47 Copper tee joint 3/8'' BH12030800010
22 Liquid level indicator * - 48 Copper connector 2 -
23 M6×15 Butterfly screw YW69061500000 49
Copper teflon pipe connector
3/8H×3/8PT(L type)
YW04030800300
24
External thread
1/4PT×1/4H
- 50
Copper teflon pipe connector
1/4H×1/4PT(L type)
YW04010400400
25
Rear plate mini cover
and mini cover fixing
plate
- 51 Elastic gasket 10 YW65010000000
26 Core 3/8"×1/2PT BH12131200010 52
Copper teflon pipe connector
3/8H×1/4PT(L type)
YW04030800200
