61(108)
Table 2-13Electrical Components List (STM-910-D) (230V)
No. Symbol Name Specification Part No.
1 Q1 Main switch* 63A YE10636300000
2 Q2 Q3 Circuit_breakers* 40A YE40604000000
3 - Excitation break away* 230V 50/60Hz YE40023560000
4 K1 K2 Contactors* 230V 50/60Hz YE00601521000
5 K3 K4 Contactors** 230V 50/60Hz YE00602722000
6 F1 F2 Overload relays 3.5~5A YE01160350000
7 F11 Fuse box** 32A 2P YE41032200000
8 - Fuse** 2A YE46002000100
9 S1 S6 Thermocouple - -
10 S2 S3 S7 S8 Thermocouple - -
11 S4 S9 Overheat protector * - -
12 S5 S10 Hydrailic switch - YE14152400000
13 PC1 PC2 Circuit board** 100~240VAC 50/60Hz
14 A1 A2 Control panel -
YE80000100000
15 Y1 Y2 Solenoid valve* 230VAC 50/60Hz
-
16 X1 Terminal board - YE61250040000
17 - Terminal board - YE61253500000
18 - Terminal board - YE61063500000
19 - Terminal board - YE61160000000
20 - Terminal board - YE61163500000
21 M1 M2 Motor** 400V 50Hz 0.75kW -
22 EH1 EH2 Heater** 400V 50Hz 9kW -
23 FM Fan* 230VAC 50/60Hz -
* means possible broken parts.
** means easy broken part. and spare backup is suggested.
Please confirm the version of manual before placing the purchase order to guarantee that
the item number of the spare part is in accordance with the real object.
