Table 2-16：Electrical Components List (STM-1220) (230V)
No. Symbol Name Specification Part No.
1 Q1 Main switch* 63A YE10636300000
2 Q2 Circuit_breakers* 60A YE40606000000
3 - Excitation break away* - YE40023560000
4 K1 Contactors* 230V 50/60Hz YE00601621000
5 K2 Contactors** 230V 50/60Hz YE00500350000
6 F1 Overload relays 7~10A YE01167100000
7 F11 Fuse box** 32A 2P YE41032200000
8 - Fuse** 2A YE46002000100
9 S1 Thermocouple - -
10 S2 S3 Thermocouple - -
11 S4 Overheat protector* - -
12 S5 Limit switch 250V 5(4) YE14152400000
13
PC1 Circuit board** 100~240VAC 50/60Hz
14
A Control panel -
YE81100010000
15
X1 Terminal board -
YE61250040000
16 - Terminal board - YE61253500000
17 -
Terminal board
- YE61043500000
18 -
Terminal board -
YE61100000000
19 - Terminal board - YE61103500000
20 Y1 Solenoid valve 230VAC 50/60Hz -
21 M1 Motor** 230V 50Hz 1.5kW -
22 EH Heater** 230V 50Hz 12kW -
23 FM Fan* 230VAC 50/60Hz -
* means possible broken parts.
** means easy broken part. and spare backup is suggested.
Please confirm the version of manual before placing the purchase order to guarantee that
the item number of the spare part is in accordance with the real object.
