No. Name Functions Remarks
9 AT AUTO-TUNING switch start and stop
Auto-tuning can run during
operation.
Auto-tuning cannot work
under SUCTION and COOL
operation.
10 SUCTION SUCTION switch start and stop
SUCTION is to remove
medium (watre/oil) from
molds. Can not start during
operation or cooling. After
SUCTION turns on,
“SUCTION relay” and “pump
inverse run relay” will turn on.
11 COOL Forced cooling switch start and stop
Press it for 2 secs for
forcedcooling, then stop
heating output while output
100% cooling control. If
control temp. is below
Cooling Temp, forced cooling
will be auto stopped then
control turns off.
12 BUZZER Turn off buzzer
Press “BUZZER” key and
“BUZZER” LED lightens;
buzzer and alarm relay are
idle even error occurs.
13 AUTO START Start and stop key
14 SUCTION OFF SUCTION relay switch start and stop
Under SUCTION is on, this
key is to turn on or off
SUCTION relay, and then
pump continues to do reverse
action.
15 F Backup
Reserve button of developing
function
16 HEAT Heating output (MAIN) display LED
17 SUB Heating output (SUB) display LED
18 COOL Cooling output display LED
19 PUMP_D Display pump running LED
20 PUMP_R Display pump inverse running LED
21 WATER Display water filling LED
22 ALARM Give the alarm LED
Refer to table 4-2 for errors
type
