ShoreTel IP Phone 230/230g Guide to Status Icons
1
Guide to Status Icons
Your ShoreTel IP phone offers icons to help indicate the call state for the device. The table below lists
the static and blinking icons, as well as the associated operational state.
Icon
Blink
Icon
230 LED Color and
Blink Pattern
230G LED Color and
Blink Pattern
State
Call Appearance States
Off Off Idle
Off Off Idle and DND
Off Off Idle and Message Waiting
Off Orange
Steady on
Idle, Message Waiting and
DND
Green
Steady on
Green
Steady on
Off Hook
Green
Steady on
Green
Steady on
Active Call
Green
Steady on
Green
Steady on
Active Conference Call
Green
Steady on
Green
Steady on
Remote Hold
Green
1000ms on, 1000ms
off
Green
1000ms on, 1000ms off
Offering Call
Green
250ms on
250ms off
Green
250ms on
250ms off
Held or Parked Call or
Conference Call
Green
Steady on
Red
Steady on
Whisper Page Call
Green
Steady on
Red
Steady on
Active Call Whisper Muted
