Step 11
Connect External Peripherals to Back-Panel
You are now ready to put the computer case back together and get on to the
external peripherals connections to your system's back-panel.
1. COM1 Port
2. VGA Port
3. SPDIF Out Port
4. GigaLAN Port
5. 10/100M LAN Port
6. USB0/1 Ports
7. PS/2 Mouse
8. PS/2 Keyboard
9. Audio Bass/Center-Out Port
10. Audio Line-In (Rear-Out) Port
11. Audio Line-Out (Front-Out) Port
2 4
1 7
11
109
3
