Shuttle FB52 - Jumpers; Back-Panel Connectors

- 26 -
Jumpers
JP2 : Clear CMOS setting
Back Panel Connectors
COM1 : Serial port 1 (DB9 male)
VGA : VGA port (DB15 female)
SPDIF_Out : SPDIF Out Port
LAN2 : GigaLAN Port
LAN1 : 10/100 base-T LAN Port
USB1 : 2 USB 2.0 (0/1) (Universal Serial Bus) ports
MS : PS/2 mouse port
KB : PS/2 keyboard port
BASS/CENTER : Audio Bass/Center-Out Port
LINE-IN : Line-In Port
LINE-OUT : Audio Line-Out Port
Front Panel Connectors
PWON : ATX power on/off momentary type switch
HLED : IDE drive active LED
GLED/PLED : Green LED (ON when system stays in power saving
mode) / System power LED
RST : Hardware reset switch
JP6/JP7 : Extended USB Headers
JP11 : Front-Panel Microphone and Line-Out Connector
Internal Peripherals Connectors
FDD : Floppy disk drive interface
IDE1 : IDE primary interface (Dual-channel)
IDE2 : IDE secondary interface (Dual-channel)
Other Connectors
CN6/CN7 : ATX power connectors
FAN1 : System fan connector
FAN2 : Chipset fan connector
C1
C2
C3
C4
D2
D3
D1
C5
E1
C6
B1
B2
B3
B4
B5
B6
B7
B8
B9
A1
B10
E2
E2
