Electrical installation
Important! Capacitive loads on the switching outputs have an effect on the switch-on and switch-off
behavior. The maximum capacity of 100 nF is a limit value.
CDM420-0001 Result 1
Chapter 4.8.9 Wiring the "Result 1" Switching Output in
the CDM420-0001 Connection Module, Page 47
Result 2
Chapter 4.8.10 Wiring the "Result 2" Switching Output
in the CDM420-0001 Connection Module, Page 48
External Input 1
(„Aux Out 1“)
Chapter 4.8.11 Wiring the "External output 1" Switch-
ing Output in the CDM420-0001 Connection Module,
Page 49
External Input 2
(„Aux Out 2“)
Chapter 4.8.12 Wiring the "External output 2" Switch-
ing Output in the CDM420-0001 Connection Module,
Page 50
