4.6.5 Wiring the Digital Switching Outputs
The two physical switching outputs "Result 1" and "Result 2" of the CLV61x can be allocated
independently of each other with various functions for the output of events in the reading
process. If the allocated event occurs, the corresponding switching output is live after the
end of the reading clock for the selected pulse duration.
Expansion: Additional logical switching outputs in the CLV61x converted to physical "exter-
nal“ switching outputs in the optional connection module
Thanks to the optional CMC600 parameter cloning module in combination with the
CDB620-001/CDM420-0001 connection module, the two additional switching outputs
"External output 1" and "External output 2" on the terminals in the connection module are
available.
Important! These two external switching outputs are not suitable for time critical applications.
The wiring of the switching outputs is done using the connection module, please see:
Connection module Switching input Chapter
CDB620-001 Sensor 1
Chapter 4.7.5 Wiring the "Sensor 1" Switching Input in
the CDB620-001 Connection Module, Page 32
Sensor 2
Chapter 4.7.6 Wiring the "Sensor 2" Switching Input in
the CDB620-001 Connection Module, Page 33
External input 1
(„Ext. In 1“)
Chapter 4.7.7 Wiring the "External input 1" Switching
Input in the CDB620-001 Connection Module, Page 34
External input 2
(„Ext. In 2“)
Chapter 4.7.8 Wiring the "External input 2" Switching
Input in the CDB620-001 Connection Module, Page 35
CDM420-0001 Sensor 1
Chapter 4.8.5 Wiring the "Sensor 1" Switching Input in
the CDM420-0001 Connection Module, Page 43
Sensor 2
Chapter 4.8.6 Wiring the "Sensor 2" Switching Input in
the CDM420-0001 Connection Module, Page 44
External input 1
(„Aux In 1“)
Chapter 4.8.7 Wiring the "External input 1" Switching
Input in the CDM420-0001 Connection Module,
Page 45
External input 2
(„Aux In 2“)
Chapter 4.8.8 Wiring the "External input 2" Switching
Input in the CDM420-0001 Connection Module,
Page 46
Connection module Switching output Chapter
CDB620-001 Result 1
Chapter 4.7.9 Wiring the "Result 1" Switching Output in
the CDB620-001 Connection Module, Page 36
Result 2
Chapter 4.7.10 Wiring the "Result 2" Switching Output
in the CDB620-001 Connection Module, Page 37
External output 1
(„Ext. Out 1“)
Chapter 4.7.11 Wiring the "External output 1" Switch-
ing Output in the CDB620-001 Connection Module,
Page 38
External output 2
(„Ext. Out 2“)
Chapter 4.7.12 Wiring the "External output 2" Switch-
ing Output in the CDB620-001 connection module,
Page 39
