SICK Lector85x Operating Instructions

Scanning fre‐
quency
30Hz, at 5megapixels resolution
20Hz, at 9megapixels resolution
15Hz, at 12megapixels resolution
Code resolution ≥0.1mm (depending on the lens)
Working distance 500mm…3,000mm
Lens C-mount
Sensor format V2D8505x–xxxxxxxxxx: 1/1.8"
V2D8509x–xxxxxxxxxx: 1/1.2"
V2D8512x–xxxxxxxxxx: 1/1.1"
1)
L
B
= Hazard from blue light.
2)
L
R
= Hazard to the retina of the eye due to heating.
3)
Not available.
10.2 Mechanics and electronics
Connection type
•
1 M12 male connector, 17-pin, A-coded (power, CAN, serial interface,
I/O)
1)

2)
•
1 M12 male connector, 5-pin, A-coded (Power, CAN)
•
3 M12 female connectors, 8-pin, X-coded (Gigabit Ethernet)
Supply voltage Vs DC 24V ±20%
Voltage source in accordance with ES1 (EN62368-1) or SELV (EN60950-1)
Power consump‐
tion
Operation: Typically 24W
3)
Current con‐
sumption
Max. 2.0A
Output current
•
Output current per output: max. 200mA
•
Sum of output currents: max. permissible 400mA
Housingmaterial Aluminum die cast
Housing color Anthracite gray (RAL7016)
Viewing window
material
Glass, 2mm thick, scratch-proof coating
Cover (top of
device)
Material: Plastic
Function
•
Inserting or removing the optional memory card
•
Temporary use of the USB interface as a service interface
Function: For temporary access to the microSD memory card slot and the
USB connection
Foldable
4)
Enclosure rating IP 65 (IEC60529:2013 +C1:2013 +C2:2015 +AMD2 C1:2019,
EN60529:1991 +A1:2010 +A2:2013 +AC:2019-02)
5)
Electrical safety EN 61010-1:2010
EN 61010-1:2010/A1:2019
EN 61010-1:2010/A1:2019/AC:2019-04
Regulatory notes NFPA79 applications only. Adapters including connecting cables are availa‐
ble.
Weight Max. 640g, without lens and connecting cables
Dimensions (L x
W x H)
143.4mm x 90mm x 46mm
6)
TECHNICAL DATA 10
8027859/1KN0/2023-08-02 | SICK O P E R A T I N G I N S T R U C T I O N S | Lector85x CAN I/O
39
Subject to change without notice
