SICK Lector85x Operating Instructions

Control of exter‐
nal illumination
unit
2)
Via digital output (max. 24V trigger) or external illumination connection
EncoderFre‐
quency
Max. 50kHz
Encoder resolu‐
tion
0.2mm/pulse…10mm/pulse
1)
For temporary use as a service interface only.
2)
Not available.
3)
If the cover is open, the device does not fulfill any specified enclosure rating. Only briefly open the cover.
Protect the device against moisture and dust during this time.
4)
Memory card is available as an optional accessory. To ensure that the memory card functions reliably,
only use card types (industrial standard) approved by SICK. Other functions are available upon request.
10.6 Ambient data
Electromagnetic
compatibility
(EMC)
Immunity: IEC61000-6-2:2016, ENIEC61000-6-2:2019
Emission: IEC61000-6-4:2018, ENIEC61000-6-4:2019
Vibration resist‐
ance
EN60068-2-6:2007, EN60068-2-64:2019
Shock resistance EN60068-2-27:2008
Ambient operat‐
ing temperature
0°C…+50°C
1)
Storage tempera‐
ture
–20°C…+70°C
2)
Permissible rela‐
tive humidity
0% ... 90%, non-condensing
Ambient light
immunity
2,000lx on code
Ambient condi‐
tions
Degree of contamination 2 (according to EN61010-1)
Altitude <5,000m above sea level
1)
If the ambient operating temperature will be ≥45°C, ensure adequate heat dissipation when mounting
the device, see "Assembling the product", page 21.
To prevent condensation, avoid exposing the device to rapid changes in temperature.
2)
Store in a place protected from moisture and dust.
10.7 Field of view diagram
Lector85x Flex
Product type: V2D8505R-xxxxxxxxxx
TECHNICAL DATA 10
8027859/1KN0/2023-08-02 | SICK O P E R A T I N G I N S T R U C T I O N S | Lector85x CAN I/O
43
Subject to change without notice
